Graphite Products Carbon Electrode UHP/HP/RP Dia 350mm Graphite Electrode With Nipple For Lf Or Eaf
| Place of Origin | China |
|---|---|
| Brand Name | Chaoyo |
| Certification | QA/QC |
| Model Number | graphite electrode |
| Minimum Order Quantity | 25tons |
| Packaging Details | wooden pallet |
| Delivery Time | 10-15days |
| Payment Terms | TT/LC |
| Supply Ability | 3000 Metric Ton/Metric Tons per Month |
Product Details
| Application | EAF / LF | Diameter | 550mm |
|---|---|---|---|
| Length | 1800mm Length | Resistance (μΩ.m) | ≤6.5 |
| Apparent Density (g/cm³ ) | ≥1.65 | Thermal Expansion | ≤2.4 |
| Flexural Strength (N/㎡) | ≥10.5 | Type | Electrode Block |
| Grade | UHP (Ultra High Power) | Connect | 4TPI |
Product Description
Graphite Products Carbon Electrode UHP/HP/RP Dia 350mm Graphite Electrode With Nipple For Lf Or Eaf
Description:
Graphite Electrodes are a high-temperature resistant graphite conductive refractory material used in the metallurgical industry. Graphite Electrodes are made of petroleum coke, bituminous coke as aggregates, coal tar pitch as binders, after raw material calcination, crushing and milling, batching, kneading, molding, roasting, impregnation, graphitization, and machining, which are also known as artificial graphite electrodes in order to distinguish from natural graphite electrodes made of natural graphite.
Specification
| RP | HP | UHP |
| Electrode: Bulk Density≥ 1.56g/cm3 Specific Resistivity≤ 8.5μm Bending Strength≥ 10.0MPa Elastic Modulus≤ 9.3GPa Thermal Expansion Coefficient≤ 2.7x10 -6/°C Ash≤ 0.5% Nipple: Bulk Density≥ 1.68g/cm3 Specific Resistivity≤ 7.0μm Bending Strength≥ 14.0MPa Elastic Modulus≤ 13.7GPa Thermal Expansion Coefficient≤ 2.5 x10 -6/°C Ash≤ 0.5% |
Electrode: Bulk Density≥ 1.65g/cm3 Specific Resistivity≤ 6.5μm Bending Strength≥ 12.0MPa Elastic Modulus≤ 10.0GPa Thermal Expansion Coefficient≤ 2.2x10 -6/°C Ash≤ 0.3% Nipple: Bulk Density≥ 1.74g/cm3 Specific Resistivity≤ 5.5μm Bending Strength≥ 16.0MPa Elastic Modulus≤ 14.0GPa Thermal Expansion Coefficient≤ 2.0 x10 -6/°C Ash≤ 0.3% |
Electrode: Bulk Density≥ 1.68g/cm3 Specific Resistivity≤ 5.8μm Bending Strength≥ 16.0MPa Elastic Modulus≤ 14.0GPa Thermal Expansion Coefficient≤ 1.9x10 -6/°C Ash≤ 0.2% Nipple: Bulk Density≥ 1.76g/cm3 Specific Resistivity≤ 4.5μm Bending Strength≥ 18.0MPa Elastic Modulus≤ 16.0GPa Thermal Expansion Coefficient≤ 1.4 x10 -6/°C Ash≤ 0.2% |
| Actual diameters | Actual lengths | ||||||
| Mm | Mm | MAX | MIN | Rough spot | Length | Tolerance | Shot Ruler size |
| 200 | 8 | 204 | 201 | 198 | 1600 | ±100 | -275 |
| 250 | 10 | 256 | 252 | 248 | 1600 1800 |
||
| 300 | 12 | 307 | 303 | 299 | |||
| 350 | 14 | 357 | 353 | 347 | |||
| 400 | 16 | 409 | 404 | 400 | 1600 1800 2000 |
||
| 450 | 18 | 460 | 455 | 451 | |||
| 500 | 20 | 511 | 506 | 502 | |||
| 600 | 24 | 613 | 607 | 604 | |||
| 780 | 31.2 | 782 | 776 | 774 | 2000 2200 2400 |
±100 | -400 |
| 800 | 32 | 802 | 796 | 794 | |||
| 870 | 34.8 | 872 | 866 | 862 | |||
| 900 | 36 | 902 | 896 | 892 | |||
| 920 | 36.8 | 922 | 916 | 912 | |||
| 960 | 38.4 | 962 | 956 | 952 | |||
| 1020 | 40.8 | 1022 | 1016 | 1012 | 2200 2600 2800 |
||
| 1060 | 42.4 | 1062 | 1056 | 1052 | |||
| 1100 | 44 | 1102 | 1092 | 1092 | |||
| 1146 | 45.8 | 1148 | 1140 | 1138 | |||
| 1197 | 47.9 | 1199 | 1191 | 1189 | |||
| 1250 | 50 | 1252 | 1244 | 1242 | |||
| 1272 | 50.9 | 1274 | 1266 | 1264 | |||
| 1305 | 54.4 | 1307 | 1299 | 1297 | |||
| 1321 | 52.8 | 1323 | 1315 | 1313 | |||
| 1400 | 56 | 1402 | 1394 | 1392 | |||
Application:
Graphite electrodes are used mainly in ladle furnaces,electric-arc furnace steelmaking,Yellow phosphorus furnace , Industrial silicon furnace or melting copper. They are presently the only products available that have the high levels of electrical conductivity and the capability of sustaining the extremely high levels of heat generated in this demanding environment.High Quality Needle Coke in HP&UHP graphite electrode,ensure the electrode application is perfect. Graphite electrodes are also used to refine steel in ladle furnaces and in other smelting processes.
Properties:
1. Good electrical conductivity.
2. Strong thermal shock resistance.
3. High mechanical strength.
Variety:
1. RP (Regular Power)
2. HP (High Power)
3. UHP (Ultra High Power)
4. RPI (Regular Power Impregnated)
(Notice: All of Graphite Electrodes is equipped to tapered nipple
Price
We produce graphite products from raw materials with vertical integration, cutting costs. Cost - effective solutions for customers' graphite needs.
Shipping
Normally 7 - 20 days after order confirmation. For urgent orders, we try the best to meet customers' request.
Post - shipment: logistics status updated in time.
Quality Control
Triple inspection covering raw materials, processing stage, and finished products. An inspection report is available for each batch of product.
After-Sale Service
Facing inevitable quality issues in manufacturing, we neither evaded nor shifted blame. Instead, we worked closely with customers to find root causes and solutions. If at fault, we took full responsibility, promptly offering free replacements.
We produce graphite products from raw materials with vertical integration, cutting costs. Cost - effective solutions for customers' graphite needs.
Shipping
Normally 7 - 20 days after order confirmation. For urgent orders, we try the best to meet customers' request.
Post - shipment: logistics status updated in time.
Quality Control
Triple inspection covering raw materials, processing stage, and finished products. An inspection report is available for each batch of product.
After-Sale Service
Facing inevitable quality issues in manufacturing, we neither evaded nor shifted blame. Instead, we worked closely with customers to find root causes and solutions. If at fault, we took full responsibility, promptly offering free replacements.
Quality Assurance & Control
· National Certified Laboratory
· Key testing instruments, including: specific resistor, bulk density meter, elasticmodulus meter, bending strength inspector, ash analysis meter, CTE analysis meter, etc.
· On-time instrument calibration
· On-site properties testing, including:
L-CTE,C-CTE
Specific resistance, bulk density,
Bending strength, ash content, elastic modulus
Production Application:
- Core application in Electric Arc Furnace (EAF) steelmaking (accounting for over 70% of global consumption): Conduct electricity to generate high-temperature electric arcs for melting scrap steel, producing construction steel, automotive steel and specialty steel
- Facilitate non-ferrous metal smelting: Smelt metals such as copper, nickel and lead; also used in vacuum remelting of refractory metals like titanium to achieve purification and uniform composition
- Produce key industrial materials: Manufacture metallurgical-grade silicon, polysilicon (for solar energy/semiconductors), as well as phosphorus and ferroalloys in submerged arc furnaces
- Serve the electrochemical industry: Act as anodes in electrolytic refining of metals like copper and gold for purification, or as current collectors in fuel cells to ensure stable electricity transmission
- Support specialized industries: Assist in high-temperature production of glass/ceramics (reducing energy consumption); also used in laboratory high-temperature experiments and electrochemical analysis
